Inverters/Variable Frequency Drives (VFD)
Serie V200
V200 Series Legacy Information
Antecedentes: The FR-V200 was Mitsubishi Electric’s 1st closed loop vector variable frequency drive. Diseñada para velocidad, posicionamiento y control de torque, la serie FR-V200E alcanzó gran precisión y tiempos de respuesta rápida que excedió el rendimiento de los inversores de aplicación general convencionales.
Ciclo de vida: discontinuado (2001)
Vida útil: El servicio de reparación no está disponible.
Información sobre migración
Originally replaced by the FR-V500 series, the new FR-A800 when used with the FR-A8AP (encoder feedback option card) would be the most suitable replacements for both the FR-V200/ FR-V500 series variable frequency drives. La tarjeta opcional de FR-A8AP es necesaria para el control del vector. Please contact your local Mitsubishi Electric office or sales channel below to discuss the VFD options that are available.
Before migrating to the FR-A800 series, we encourage our customers to review the factory VFD transition guide to confirm dimensions, options and specifications prior to upgrading inverters.
Nota: The rated current value of the FR-V200/V500 series was larger than that of the FR-A800 series. Cuando reemplace el FR-V200/V500 con la serie A800 use un inversor de la serie FR-A800 con un grado mayor de capacidad de tamaño con respecto al inversor de la serie FR-V500.
Suggested Replacements: The tables below list affected V200/V500 products and suggested replacements. Confirme todas las especificaciones con los manuales aplicables.
| FR-V220-240V | FR-V520-240V | FR-A820-240V |
|---|---|---|
| FR-V220E-1.5K | FR-V520-1.5K | FR-A820-00167-1-N6 |
| FR-V220E-2.2K | FR-V520-2.2K | FR-A820-00250-1-N6 |
| FR-V220E-3.7K | FR-V520-3.7K | FR-A820-00340-1-N6 |
| FR-V220E-5.5K | FR-V520-5.5K | FR-A820-00490-1-N6 |
| FR-V220E-7.5K | FR-V520-7.5K | FR-A820-00630-1-N6 |
| FR-V220E-11K | FR-V520-11K | FR-A820-00770-1-N6 |
| FR-V220E-15K | FR-V520-15K | FR-A820-00930-1-N6 |
| FR-V220E-18.5K | FR-V520-18.5K | FR-A820-01250-1-N6 |
| FR-V220E-22K | FR-V520-22K | FR-A820-01540-1-60 |
| FR-V220E-30K | FR-V520-30K | FR-A820-01870-1-60 |
| FR-V220E-37K | FR-V520-37K | FR-A820-02330-1-60 |
| FR-V220E-45K | FR-V520-45K | FR-A820-03160-1-60 |
| FR-V220E-55K | FR-V520-55K | FR-A820-03800-1-60 |
| FR-V240-480V | MFR-V540-480V | FR-A840-480V |
|---|---|---|
| FR-V240E-1.5K | FR-V540-1.5K | FR-A840-00083-1-N6 |
| FR-V240E-2.2K | FR-V540-2.2K | FR-A840-00126-1-N6 |
| FR-V240E-3.7K | FR-V540-3.7K | FR-A840-00170-1-N6 |
| FR-V240E-5.5K | FR-V540-5.5K | FR-A840-00250-1-N6 |
| FR-V240E-7.5K | FR-V540-7.5K | FR-A840-00310-1-N6 |
| FR-V240E-11K | FR-V540-11K | FR-A840-00380-1-N6 |
| FR-V240E-15K | FR-V540-15K | FR-A840-00470-1-N6 |
| FR-V240E-18.5K | FR-V540-18.5K | FR-A840-00620-1-N6 |
| FR-V240E-22K | FR-V540-22K | FR-A840-00770-1-60 |
| FR-V240E-30K | FR-V540-30K | FR-A840-00930-1-60 |
| FR-V240E-37K | FR-V540-37K | FR-A840-01160-1-60 |
| FR-V240E-45K | FR-V540-45K | FR-A840-01800-1-60 |
| FR-V240E-55K | FR-V540-55K | FR-A840-02160-1-60 |
