Controllers MELSEC iQ-R Series
Product features -Basic system configuration-
- Concepto
- Solución
- Registrador de sistemas
- Basic system configuration
- Línea
- CPU
- E/S
- Analógico
- Temperature input module, Temperature control module
- Motion, Positioning
- High-speed counter, Channel isolated pulse input, Flexible high-speed I/O control
- Red
- Advanced information
- Energy measuring
- Software
- Factory automation partner products
Basic system configuration
- ABase unit
- Variety of base units are available according to the number of modules required to install
- Base units and extension base units with many slots support future system expansion
- BPower supply module
- Efficiently supplies power to all modules installed on the base unit
- CCPU module
- Wide range of modules catering to all control needs
- The core of the programmable controller system
- DI/O module
- Easily add appropriate modules from diversified lineups according to applications
- ENetwork module
- For connecting multiple systems
- FAdvanced information module
- Provides connectivity with IT systems for data communications and analysis
The MELSEC iQ-R Series is a modular control system equipped with various modules, each having its own responsibility in a system, enabling selection of appropriate modules according to the application.
This modular design allows easy replacement of faulty modules when an error occurs and addition of necessary modules for system expansion.
Módulos de fuente de alimentación
| Artículo | Power supply module | Slim type fuente de alimentación general |
Redundant power supply module | ||||||
|---|---|---|---|---|---|---|---|---|---|
| R61P | R62P | R63P | R64P | R69P | R61SP | R63RP | R64RP | R69RP | |
| Input power voltaje de fuente de alimentación |
100…240 V AC (85… 264 V AC) |
100…240 V AC (85… 264 V AC) |
24 V CC (15,6… 31,2 V CC) |
100…240 V AC (85… 264 V AC) |
24 V CC (19,2… 31,2 V CC) |
100…240 V AC (85… 264 V AC) |
24 V CC (15,6… 31,2 V CC) |
100…240 V AC (85… 264 V AC) |
24 V CC (19,2… 31,2 V CC) |
| Frecuencia de entrada | 50/60 Hz ±5% |
50/60 Hz ±5% |
- | 50/60 Hz ±5% |
- | 50/60 Hz ±5% | - | 50/60 Hz ±5% | - |
| Max. input Potencia aparente (VA) |
130 | 120 | - | 160 | - | 45 | - | 160 | - |
| Max. input power (W) | - | - | 50 | - | 65 | - | 50 | - | 65 |
| Salida nominal current (5 V DC, A) |
6,5 | 3,5 | 6,5 | 9 | 9 | 2,5 | 6,5 | 9 | 9 |
| Salida nominal current (24 V DC, A) |
- | 0,6 | - | - | - | - | - | - | - |
Unidades base
| Artículo | Unidad base principal | Slim type main base unit | Redundant fuente de alimentación unidad base principal |
Extended temp. range main base unit*1 | ||||||
|---|---|---|---|---|---|---|---|---|---|---|
| R33B | R35B | R38B | R312B | R32SB | R33SB | R35SB | R310RB | R310B-HT | R38RB-HT | |
| Number of I/O modules installed | 3 | 5 | 8 | 12 | 2 | 3 | 5 | 10 | 10 | 8 |
| DIN rail mounting adapter type | R6DIN1 | R6DIN1 | R6DIN1 | R6DIN1 | R6DIN1 | R6DIN1 | R6DIN1 | R6DIN1 | R6DIN1 | R6DIN1 |
| External dimensions (H × W × D, mm) | 101×189 × 32,5 |
101×245 × 32,5 |
101×328 × 32,5 |
101×439 × 32,5 |
101×114 × 32,5 |
101×142 × 32,5 |
101×198,5 × 32,5 |
101×439 × 32,5 |
101×439 × 32,5 |
101×439 × 32,5 |
Unidades base de extensión
| Artículo | Extension base unit (Standard) | Extended temp. range extension base unit*1 | ||||||
|---|---|---|---|---|---|---|---|---|
| R65B | R68B | R612B | R610RB | R68WRB | R610B-HT | R68RB-HT | R66WRB-HT | |
| Number of I/O modules installed | 5 | 8 | 12 | 10 | 8 | 10 | 8 | 6 |
| Módulo aplicable | MELSEC iQ-R Series module | |||||||
| DIN rail mounting adapter type | R6DIN1 | R6DIN1 | R6DIN1 | R6DIN1 | R6DIN1 | R6DIN1 | R6DIN1 | R6DIN1 |
| External dimensions (H × W × D, mm) | 101×245 × 32,5 |
101×328 × 32,5 |
101×439 × 32,5 |
101×439 × 32,5 |
101×439 × 32,5 |
101×439 × 32,5 |
101×439 × 32,5 |
101×439 × 32,5 |
RQ extension base units
| Artículo | RQ extension base unit | ||
|---|---|---|---|
| RQ65B | RQ68B | RQ612B | |
| Number of I/O modules installed | 5 | 8 | 12 |
| Módulo aplicable | MELSEC-Q Series module | ||
| DIN rail mounting adapter type | Q6DIN2 | Q6DIN1 | Q6DIN1 |
| External dimensions (H × W × D, mm) | 98 × 245 × 44,1 | 98 × 328 × 44,1 | 98 × 439 × 44,1 |
Cable de extensión
| Artículo | RC06B | RC12B | RC30B | RC50B | RC100B |
|---|---|---|---|---|---|
| Cable length*2 (m) | 0,6 | 1,2 | 3,0 | 5,0 | 10,0 |
- *1.Enables standard MELSEC iQ-R Series modules to support extended operating ambient temperature of 0 to 60°C.
- *2.Overall cable distance 20 m. 13,2 m with the RQ extension base.
