Programmable Controllers MELSEC-A Series

Renewal

img-mv-1-sm

Replace high-speed counter module without restrains from specifications of the connected external devices

Modules for Easy Replacement

Supported series: A/QnA AnS/QnS

Plentiful Q Series modules facilitate the replacement

Módulo de recuento de alta velocidad

To replace a high-speed counter module without considering the specification of the existing pulse generator (encoders, etc.).

Configuración de interruptor de velocidad de recuento A/QnA Series AnS/QnAS Series Serie Q
50K PPS AD61 A1SD61 QD62-H01
10K PPS AD61S1 QD62-H02
  • Nota: In some cases, the "limit switch output function" of A1SD61 can be replaced by the "coincidence output function" of QD62-H01/H02.

Related documents

Programmable Controllers MELSEC-A/QnA (Large), AnS/QnAS (Small) Transition Examples
2021-12
Manual de transición de la serie MELSEC-A/QnA (grandes) a la serie Q (Módulos de funciones inteligentes)
2020-02
Manual de transición de la serie MELSEC-AnS/QnAS (pequeños) a la serie Q (módulos de funciones inteligentes)
2020-02
