Upgrading to the L Series while keeping the existing wiring unchanged

Upgrade example

AnS/L Upgrade Tool Products

Supported series: AnS/QnAS-L

Benefits of replacing the AnS/QnAS Series with the L Series

  • Increases the production capacity and shortens the operating cycle.
    The L Series programmable controllers speed up the operation and processing speed (as fast as about 5 times the processing performance of the AnS Series) and the bus communication speed.
    Upgrading the AnS/QnAS Series to the L Series significantly improves the production capacity.
  • Enables a flexible configuration without a base
    The L Series does not need a base unit. Its installation footprint is minimum, which otherwise restricted by the size of the base unit. When adding modules, the number of slots on a base unit does not have to considered. The base-less architecture often eliminates the need of additional extension base units, saving the system cost.
  • Reduces the system cost by using built-in CPU functions
    The LCPU module is equipped with a number of built-in functions such as the general input, interrupt input, pulse catch, general output, high speed counter, positioning, Ethernet and CC-Link communication functions.
    Combining the built-in functions eliminates the needs of modules dedicated to each function, and such combined functions realize a variety of control functions while reducing the system cost.

L Series replacement example with the AnS/L upgrade tool products (conversion adapter, base adapter) and L Series space modules

  1. (1)Remove the existing AnS/QnAS Series programmable controllers together with the base unit. Install the AnS/L base adapter.
    (The existing installation holes can be used as they are. No additional holes need to be created.)
  2. (2)Install a space module on the left side of the L Series module to which an AnS/L conversion adapter (terminal block type) will be attached.
  3. (3)Attach the AnS/L conversion adapters to the L Series modules.
  4. (4)Remove the wiring terminal block from the existing AnS/QnAS Series module and connect that wiring terminal block to the conversion adapter.
  1. Nota 1: Use of the L Series space module may restrict the system configuration. Please refer to "MELSEC-L CPU Module User's Manual (Hardware Design, Maintenance and Inspection)" (SH-080890ENG) for the detailed specifications, cautionary notes and restrictions.
  2. Note 2: Upgrading to the L Series module could result in a wider system width than the system width using the AnS/QnAS (small type). Please refer to "Transition from MELSEC-AnS/QnAS (Small Type) Series to L Series Handbook (Fundamentals)"(L(NA)08258ENG) for more details.

AnS/L upgrade tool products

The AnS/L upgrade tool products consists of two items-"conversion adapter" and "base adapter". The conversion adapter supports the conversion of the AnS/QnAS Series I/O and analog modules wiring to the corresponding L Series modules wiring. The base adapter is used to utilize the existing installation holes of the AnS/QnAS Series base units for the L Series programmable controller installation.

List of conversion adapters

For input/output modules <Single module type>

Entrada/salida MELSEC AnS/QnAS Series
module model
MELSEC L Series
module model
Conversion adapter model Space module
(LG69)
Entrada A1SX10, A1SX10EU LX10 ERNT-ASLTXY10 Can be used
A1SX40, A1SX40-S1, A1SX40-S2 LX40C6 ERNT-ASLTX40 Can be used
A1SX41, A1SX41-S1, A1SX41-S2 LX41C4 Unnecessary.
The connector shape is the same.
Innecesario
A1SX42, A1SX42-S1, A1SX42-S2 LX42C4 Unnecessary. The connector shape is the same. Innecesario
A1SX71 LX41C4 Unnecessary. The connector shape is the same. Innecesario
A1SX80, A1SX80-S1, A1SX80-S2 LX40C6 ERNT-ASLTX80 Can be used
A1SX81, A1SX81-S2 LX41C4 ERNT-ASLCXY81 Innecesario
A1SX82-S1 LX42C4 Unnecessary. The connector shape is the same. Innecesario
Salida A1SY10, A1SY10EU LY10R2 ERNT-ASLTXY10 Can be used
A1SY22 LY20S6 ERNT-ASLTY22 Can be used
A1SY40, A1SY40P LY40NT5P ERNT-ASLTY40 Can be used
A1SY41, A1SY41P LY41NT1P Unnecessary. The connector shape is the same. Innecesario
A1SY42, A1SY42P LY42NT1P Unnecessary. The connector shape is the same. Innecesario
A1SY50 LY40NT5P ERNT-ASLTY50 Can be used
A1SY80 LY40PT5P ERNT-ASLTY80 Can be used
A1SY81, A1SY81EP LY41PT1P ERNT-ASLCXY81 Innecesario
A1SY82 LY42PT1P Unnecessary. The connector shape is the same. Innecesario
Input and
salida
A1SH42, A1SH42P LH42C4NT1P Unnecessary. The connector shape is the same. Innecesario
A1SH42-S1, A1SH42P-S1 LH42C4NT1P Unnecessary. The connector shape is the same. Innecesario

For analog modules <Single module type>

Entrada/salida MELSEC AnS/QnAS
Series module model
MELSEC L Series
module model
Conversion adapter model Space module
(LG69)
Entrada A1S64AD L60AD4 ERNT-ASLT64AD Can be used
Salida A1S62DA L60DA4 ERNT-ASLT62DA Can be used

For high-speed counter modules <Single module type>

MELSEC AnS/QnAS
Series module model
MELSEC L Series
module model
Conversion adapter model Space module (LG69)
A1SD61 LD62 ERNT-ASLTD61 Can be used
A1SD62 ERNT-ASLTD62 Can be used

List of base adapters

Tipo de módulo MELSEC AnS/QnAS
Series module model
Base adapter model
Unidad base principal A1S32B ERNT-ASLB32
A1S33B ERNT-ASLB33
A1S35B ERNT-ASLB35
A1S38B, A1S38HB ERNT-ASLB38
Type requiring power supply module A1S65B ERNT-ASLB65
A1S68B ERNT-ASLB68
Tipo de módulo MELSEC AnS/QnAS
Series module model
Base adapter model
Type not requiring power supply module A1S52B ERNT-ASLB52
A1S55B ERNT-ASLB55
A1S58B ERNT-ASLB58
Type unifying CPU,
power supply and base unit
A1SJCPU ERNT-ASLBJ
A1SJCPU-S3
A1SJHCPU

Installing the conversion and base adapters

The wiring of the AnS/QnAS Series modules can be used as it is for the L Series modules.

Upgrade tool products contents

Conversion adapter
Base adapter*

For utilizing the installation holes of the AnS/QnAS Series modules for the L Series installation.

Upgrading to the L Series module could result in a wider system width than the system width using the AnS/QnAS. If the width after upgrading is impractical, consider use of a DIN rail for installation.
Please refer to "Transition from MELSEC-AnS/QnAS (Small Type) Series to L Series Handbook (Fundamentals)" (L(NA)08258ENG) for more details.

  1. Note 1:Use of the L Series space module may restrict the system configuration. Please refer to "MELSEC-L CPU Module User's Manual (Hardware Design, Maintenance and Inspection)" (SH-080890ENG) for the detailed specifications, precautions and restrictions.
